MiniZed

The MiniZed is a compact, single-board development platform built around the Xilinx Zynq-7000 SoC (XC7Z007S), combining a dual-core ARM Cortex-A9 processor with programmable FPGA logic in a single chip. Designed for embedded developers and makers who need real processing power in a tiny footprint.

Key Features

• SoC: Xilinx Zynq-7000 XC7Z007S — ARM Cortex-A9 @ 667MHz + FPGA logic
• RAM: 512MB DDR3L
• Storage: 8GB eMMC flash + MicroSD card slot
• Wireless: Wi-Fi 802.11b/g/n & Bluetooth 4.1 (Murata LBEE5KL1DX)
• USB: USB 2.0 OTG (micro-USB), USB-UART bridge for serial console
• Expansion: 1× Pmod connector, Arduino-compatible single-row header
• GPIO: PS and PL GPIO accessible via expansion headers
• Power: 5V via micro-USB
• Form Factor: 2" × 3.5" (51mm × 89mm)
• OS Support: PetaLinux, Ubuntu, FreeRTOS

What's Included

• 1× MiniZed development board
• Micro-USB cable

Ideal For

Embedded Linux development, FPGA prototyping, robotics control systems, IoT edge computing, and hardware/software co-design projects. A great entry point into Zynq-based development without the cost of a full evaluation kit.
